R&S also offers economical roll-up curtain doors, mullions and header panels for self-storage applications. Whether it is new construction or replacement, R&S is able to meet the need for secure, effective, space saving closures while providing outstanding economy and value. Color options are available.

R&S uses DBCI, one of the top manufacturers of steel curtain roll-up doors and components for the self-storage and commercial door markets.

Contact us today to have a free on site evaluation of your rolling curtain doors!

Light Duty Roll-Up Doors

Light Cycles

The 650 Series from DBCI is ideal for light-duty use in carports, barns, sheds and self-storage/commercial unit mix. It was engineered to protect and maintain building envelopes in extreme conditions without the heavy, weighted elements frequently required in commercial use. Available in sizes up to 10’ x 10’ and in more than 30 colors, customized for your application; manufactured to be durable and easy to install with little maintenance required.

Specifications

Curtain

  • 26-gauge galvanized, Grade 80 steel
  • 5/8″ ribbed corrugation
  • All latches accept double locks and 7/16″ shackles
  • Max opening size 10′ x 10′
  • Super-durable polyester paint

Bottom Bar

  • 1 1/2″ x 1 1/2″ galvanized angles
  • Replaceable bulb astragal

Dead Axle-Drum Assembly

  • 1 5/16″ O.D. steel axle, 14-gauge
  • Utilizes 9 1/2″, 18-gauge drums
  • Oil-tempered helical torsion springs are factory lubricated
  • Full-accessible springs for inspection and maintenance

Guide System

  • 18-gauge galvanized steel
  • Polyethylene guide strips provide easy, quiet operation

Hardware

  • 12-gauge head stops have slotted mounting holes for proper attachment
  • 14-gauge galvanized steel handles
  • 12-gauge tension bracket made for additional strength
  • Shielded radial bearings for smooth operation
  • Gear-driven tensioning bracket allows for smooth adjustment
  • 12-gauge bearing bracket on right side
  • Stainless steel standard latch

Options Available in sizes up to 10′ x 10′ and in over 30 different colors

High Cycles

The 2000 Series from DBCI is the perfect door for light-duty applications that require frequent use. These quality, low-maintenance roll-up steel doors are ideal for warehouses, car washes, machine shops, auto body shops, and more. DBCI’s commercial-grade steel curtains are designed to meet or exceed operational requirements, and the 16-gauge 12″ drums are easy to retract and maintain. Available in more than 30 colors.

Specifications

Curtain

  • 26-gauge galvanized, Grade 80 steel
  • 5/8″ ribbed corrugation
  • Max opening size 12′ x 16′
  • Super-durable polyester paint

Bottom Bar

  • 2″ x 1 1/2″ galvanized angles
  • Bulb astragal
  • Stainless steel nuts and bolts

Dead Axle-Drum Assembly

  • 1 5/16″ O.D. steel axle, 14-gauge
  • Utilizes 12″, 16-gauge drums
  • Shielded steel ball bearings in drums
  • Pre-lubricated, enclosed springs

A.C.E. (Advanced Curtain Engagement) Guide System

  • 16-gauge galvanized steel
  • Adjustable bolt on head stop
  • Polyethylene wear strip
  • Pre-punched holes for lock and attachment fasteners

Hardware

  • Saddle clamps with set fasteners
  • Slide locks, two per door
  • Step plate, two per door
  • 1/4″ steel angle T-bracket

Options

  • Chain hoist 4:1 reduction
  • Vision panels
  • Hood
  • Steel mounting plates
  • Motor operated

Available in more than 30 color options

Heavy Duty Roll-Up Doors

Freight & Warehouse

The DBCI’s 2500 Series is a heavy-duty sheet door suitable for warehouse and freight buildings. It has deep engagement guides, ensuring superior durability and strong, long-lasting performance. Available in more than 30 colors.

Specifications

Curtain

  • 26-gauge galvanized, Grade 80 steel
  • 5/8″ ribbed corrugation
  • Max opening size 18′ x 18′
  • Super-durable polyester paint

Bottom Bar

  • 24 gauge acrylic-coated galvalumed roll formed steel
  • 2” x 1 ½” galvanized angle
  • Bulb astragal (Durometer 75)
  • Stainless steel nuts and bolts

Axle/Torque Tube

  • 1-5/16” O.D. steel axle, 14-gauge
  • Oil tempered torsion springs conforming to ASTM A229
  • 16-gauge, 12” diameter galvanized drum
  • Low friction, grease-filled steel ball bearings staked in each drum
  • 26 gauge spiral torque tubing that houses axle assembly

Guides

  • 14-gauge galvanized steel
  • Adjustable bolt on head stop
  • Polyethylene wear strip
  • Pre-punched holes for lock and attachment fasteners

Hardware

  • Saddle clamps with set fasteners
  • slide locks, two per door
  • Step plate, two per door
  • 1/4″ steel angle T-bracket
  • Steel “T” shaped head stop

Options

Commercial Grade

DBCI’s 3000 Series commercial-grade steel door is built with superior, high-strength materials and is engineered to withstand moderate to high wind loads common in many coastal regions. The 3000 Series features ribbed corrugation with an “L” shaped windlock design that grips in place under high pressure, and an 80-degree profile that makes installation fast and easy.

Specifications

Curtain

  • 26-gauge galvanized, Grade 80 steel
  • 5/8″ ribbed corrugation
  • Max opening size 20′ x 16′
  • Super-durable polyester paint

Bottom Bar

  • 6063 – T6 aluminum extrusion
  • Bulb astragal
  • Stainless steel nuts and bolts

Axle/Torque Tube

  • Oil tempered torsion springs conforming to ASTM A229
  • 16-gauge, 12” diameter galvanized drum
  • Low friction, grease-filled steel ball bearings staked in each drum
  • 26 gauge spiral torque tubing that houses axle assembly

Guides

  • 14-gauge galvanized steel
  • 14-gauge wind lock bar
  • Adjustable bolt on head stop
  • Polyethylene wear strip
  • Pre-punched holes for lock and attachment fasteners

Hardware

  • Saddle clamps with set fasteners
  • Slide locks, two per door
  • Step plate, two per door
  • 1/4″ steel angle T-bracket
  • Steel “T” shaped head stop

Options

  • Chain hoist 8:1 reduction
  • Header seal
  • Hood
  • Steel mounting plates
  • Motor operator
  • Available in more than 30 color options, subject to availability and varying lead times

Frames & Panel Systems

Roll-Up Frames

The roll-up frame is a non-load bearing interior hallway jamb for attaching DBCi roll-up doors. The strong, flush 20-gauge frame is used in both corrugated and flush hallway systems and is available in glossy white or Galvalume. Includes base plates, back plates and top channel.

  • 20-gauge
  • Siliconized polyester Weather X paint finish
  • Press break construction for variable sizes
  • 20-gauge back plate for mounting header/filler panel and roll up door bracket
  • 20-gauge base plate that mounts roll-up frame to floor
  • #8 x 1/2″ glossy white self drilling screws
Flush Header Panel

Encloses the area just above the storage door with a smooth header panel to ensure your valuables are kept secure and create a clean, flush hallway aesthetic. This panel is only available in High Gloss White.

  • 20- gauge panel
  • For interior hallway systems
  • Single-piece construction
  • #8×1/2” glossy white self-drilling fasteners
Filler Panel

Filler panels are used in interior and exterior applications and enclose the area just above the storage door with a corrugated header panel. Secures and maintains the aesthetics of your hallway system.

  • Can be matched to the color of the door, as well as the angles
  • 26-gauge panel, support channel and angles
  • Framed in at the sides, top and bottom with matching support channels
  • #8 x ½” self-drilling fasteners available
